PB Vision Partner Documentation

For policies, pricing, and partner responsibilities refer to our API Partner Guide.

The easiest way to use the PB Vision AI Engine is to simply share a link to your video file. Our AI usually works on each video for about 30 minutes for a standard length game, so we'll notify your servers when the results are ready.

Installation

Step 1: Get API Access

Email support@pb.vision to request API access for your account. Let us know which data you need access to (e.g. insights, stats) which is documented below in the Callback Data section. We'll send you an API Key after discussing your needs more in depth and laying out our billing options.

Step 2: SDK Setup

  1. Install node
  2. Install the SDK: npm i @pbvision/partner-sdk
  3. In your package.json, make sure you're configured to use ESM (modules): "type": "module"
  4. Initialize the SDK:
import { PBVision } from '@pbvision/partner-sdk';
const pbv = new PBVision(YOUR_API_KEY);
  1. Use its methods as described to send us video URLs to to process, or tell us your webhook's URL.

Using the API

Webhook Setup

Each time our AI finishes processing a video, it will notify your servers via an HTTP POST request to a URL ("webhook") of your choice. You can use our SDK to tell our servers where you want us to notify your servers like this:

import { PBVision } from '@pbvision/partner-sdk';

const pbv = new PBVision(YOUR_API_KEY);
await pbv.setWebhook(YOUR_WEBHOOK_URL);

Alternatively, you can just use curl:

curl -X POST \
     -H 'x-api-key: YOUR_API_KEY' \
     -H 'Content-Type: application/json' \
     -d '{"url": "https://YOUR_WEBHOOK_URL"}' \
     https://api-2o2klzx4pa-uc.a.run.app/partner/webhook/set

Send Videos

Option 1: PBV downloads your video from a URL

First, upload a video to a publicly accessible URL on your server. For best results, videos should follow our guidelines.

Next, tell us to download and work on the video. You can do this using our SDK:

import { PBVision } from '@pbvision/partner-sdk';

const pbv = new PBVision(YOUR_API_KEY, { useProdServer: true });
const metadata = {
  userEmails: ['player1@example.com', 'player2@example.com'],
  name: 'Dink Championship 2025',
  gameStartEpoch: 1711393200,
};
const { vid } = await pbv.sendVideoUrlToDownload(YOUR_VIDEO_URL, metadata);

Alternatively, you can just use curl:

curl -X POST \
     -H 'x-api-key: YOUR_API_KEY' \
     -H 'Content-Type: application/json' \
     -d '{"url": "https://YOUR_VIDEO_URL", "userEmails": ["test@example.com"]}' \
     https://api-2o2klzx4pa-uc.a.run.app/partner/add_video_by_url

Option 2: Upload your video

You can directly upload your video from a file using the SDK too:

import { PBVision } from '@pbvision/partner-sdk';

const pbv = new PBVision(YOUR_API_KEY, { useProdServer: true });
const metadata = {
  userEmails: ['player1@example.com'],
  name: 'My Game',
  gameStartEpoch: 1711393200,
};
const { vid } = await pbv.uploadVideo(YOUR_VIDEO_FILENAME, metadata);

uploadVideo() sends the file in chunks and resumes by itself after a dropped connection or a temporary error. If the upload still fails, the error it throws has the video's ID as its vid property. To retry without making a second video for the game, pass a nonce that identifies the game (see makeVideoId()): every call with the same nonce uploads to the same video.

Option 3: Pre-allocate a video ID (record/upload elsewhere)

Use makeVideoId() to reserve a video ID without uploading a file yourself. This is handy when the video will be recorded and uploaded by a different client. Hand the returned vid (and uid) to that client so it uploads to this video instead of allocating a new one.

To have the game recorded with the PB Vision app, use makeRecordingLink() instead: it reserves the video ID for you and returns a link that opens the app's camera to record into it. See Recording with the PB Vision app.

const { vid, uid, hasCredits } = await pbv.makeVideoId({
  // same metadata fields as the other upload methods (all optional)
  name: 'My Game',
  fileExt: 'mp4', // the extension it will be uploaded as (defaults to "mp4")
  playersForTagging: { server: { name: 'Alice', email: 'alice@example.com' }, receiver: { name: 'Bob' } }
});

If the account paying for the video can't pay for it, hasCredits is false and there is no vid. Passthrough partners always get hasCredits.

Video Metadata

sendVideoUrlToDownload(), uploadVideo(), makeVideoId(), and makeRecordingLink() accept an optional metadata object. You can omit it entirely, or provide some or all of these fields:

Field Type Description
userEmails string[] Up to 4 email addresses of players in the game. These users will have the video added to their PB Vision library, become editors on the video, and be notified when processing is complete.
name string Title of the game. Defaults to the game time, or the upload time if no game time is provided.
desc string A longer description of the game.
gameStartEpoch integer Unix timestamp (seconds) of when the game was played. Not taken by makeRecordingLink(), where the game's time comes from its recording.
facility string Name of the facility where the game was recorded, e.g. "Cool Club #3 - Barcelona". Useful for facility and Court Insight integrations.
court string Court identifier where the game was recorded, e.g. "11A". Useful for facility and Court Insight integrations.
fid integer Folder ID, e.g. from getOrCreateFolder() (see Folders). Puts the video in that folder in your partner account's library. A fid that isn't one of your folders is refused with a 400 error (unknown folder).
playersForTagging object The players to auto-tag once processing completes, each by a name, an email, or both (see Auto-tagging players). Honored by all of uploadVideo(), sendVideoUrlToDownload(), makeVideoId(), and makeRecordingLink().

The facility and court fields are primarily used by facility partners running Court Insight or similar venue-based integrations, where tracking which court a game came from is important. League and tournament partners may also find these useful for organizing videos by location.

Auto-tagging players

Provide playersForTagging to have PB Vision tag the players automatically once the video is processed. Identify each player by their role at the start of the first game, and give each one a name, an email, or both:

const { vid } = await pbv.uploadVideo(YOUR_VIDEO_FILENAME, {
  playersForTagging: {
    server: { name: 'Alice', email: 'alice@example.com' },       // served the first point
    serverPartner: { name: 'Carol' },                            // omit for singles
    receiver: { email: 'bob@example.com' },                      // received the first point
    receiverPartner: { name: 'Dave', email: 'dave@example.com' } // omit for singles
  }
});

To fill in the roles from a match:

  • The team that serves first supplies the server (its first server) and the serverPartner.
  • The other team's first server is the receiver: they start on the right and receive the first serve. Their partner is the receiverPartner.
  • For singles, omit serverPartner and receiverPartner.

How each player is tagged depends on what you provide:

  • A player with an email is emailed that they were tagged. If the email belongs to a PB Vision account, the game is added to that account's library and the account's own name is shown. If not, the name you gave is shown, and the game joins their library when they sign up with that email.
  • A player with only a name is labeled with that name.

server and receiver are required when playersForTagging is present. Names are 1 to 64 characters (after trimming), and each email may be used for only one player. In multi-game videos the same players are matched across games automatically.

Folders

Folders organize the videos in your partner account's library. To put a new video in a folder, pass the folder's ID as the fid metadata field.

getOrCreateFolder() returns the folder with the name you give (inside parent, if you pass one), creating it if needed, so it's safe to retry. Use a unique name for each event, such as one that includes its date. Names are 1 to 200 characters, with no leading or trailing whitespace.

// a folder at the top level of your library
const { fid, created } = await pbv.getOrCreateFolder('Spring Open 2026-04-18'); // created: true if new

// a folder inside it
const { fid: day1Fid } = await pbv.getOrCreateFolder('Day 1', { parent: fid });

updateFolder() renames a folder, moves it, or makes it public. Fields you leave out stay as they are:

await pbv.updateFolder(fid, { name: 'Spring Open 2026' }); // rename it
await pbv.updateFolder(day1Fid, { parent: null });         // move it to the top level
await pbv.updateFolder(fid, { public: true });             // let anyone with its link view it
await pbv.updateFolder(day1Fid, { public: true });         // and include Day 1 when it's viewed

Anyone with a public folder's link can view its videos, signed in or not. A folder inside it is included only if it's public too. getPublicFolderUrl() gives you the link:

const folderUrl = pbv.getPublicFolderUrl(fid);
// https://pb.vision/library/public/<uid>/<fid>

Recording with the PB Vision app

For each game, makeRecordingLink() makes a video with the metadata you give it and returns a link. Opening the link on a phone takes the PB Vision app straight to its camera, and the recording uploads to that video in your partner account. Anyone can record from the link, signed in to PB Vision or not.

A typical event goes like this:

  1. Create a folder for the event with getOrCreateFolder(), using a name that is unique to the event (see Folders).
  2. Make a recording link for each game with makeRecordingLink(), putting the game in the event's folder and naming its players so they are tagged automatically.
  3. Share the folder: make it public with updateFolder() and send out the link from getPublicFolderUrl().
import { PBVision } from '@pbvision/partner-sdk';

const pbv = new PBVision(YOUR_API_KEY, { useProdServer: true });

// 1. one folder per event
const { fid } = await pbv.getOrCreateFolder('Spring Open 2026-04-18');

// 2. one recording link per game
const { vid, url } = await pbv.makeRecordingLink({
  name: 'Spring Open, Court 3, Round 1',
  fid,
  court: '3',
  playersForTagging: {
    server: { name: 'Alice', email: 'alice@example.com' },
    serverPartner: { name: 'Carol' },
    receiver: { name: 'Bob', email: 'bob@example.com' },
    receiverPartner: { name: 'Dave' }
  }
});
// save `vid` with the game in your own records
// show `url` as a QR code, or send it to whoever is recording the game

// 3. share the event
await pbv.updateFolder(fid, { public: true });
const eventUrl = pbv.getPublicFolderUrl(fid);

makeRecordingLink() returns { vid, uid, url }. It takes the same metadata as the other methods except gameStartEpoch (the game's time comes from its recording). It throws if the account paying for the video can't pay for it.

One link per game. If several people may ask for the same game's link, pass a nonce that identifies the game, such as your own ID for it. Every call with that nonce returns the same video and link, even at the same moment, and the first call's metadata is used. makeVideoId() takes a nonce too.

const { url } = await pbv.makeRecordingLink({ nonce: `${eventId}-${gameId}`, fid, playersForTagging });

Camera settings. By default the link records at 1080p and 30 FPS, and the person recording can't change either. Ask for 4K with resolution: '4k' or 60 FPS with fps: 60; with mayChangeResolution: true or mayChangeFPS: true the person recording may choose lower settings. Phones step down to what they support, and recorders don't need a PB Vision subscription. 4K requires your partner account to have 4K enabled, since PB Vision doesn't analyze video above 1080p without it. getMyPartnerAccountInfo() says whether yours does, and without it makeRecordingLink() refuses resolution: '4k'.

const { is4K } = await pbv.getMyPartnerAccountInfo();
const { url } = await pbv.makeRecordingLink({
  fid,
  resolution: is4K ? '4k' : '1080p', // '1080p' (default) or '4k'
  fps: 60,                   // 30 (default) or 60
  mayChangeResolution: true, // default false
  mayChangeFPS: false        // default false
});

One recording per link. Only the first upload to a link's video counts.

Opening the link. Let the phone open the link: a tap, a scanned QR code, or your app handing it to the operating system (UIApplication.shared.open() on iOS, an ACTION_VIEW intent on Android). Don't load it in a webview or an in-app browser, where the PB Vision app may not open. Without the app, the link shows a page for installing it.

Testing. Links from the test server (useProdServer: false) start with pbvision://record and need a development build of the PB Vision app.

Video Editors and Viewers

Editors can tag themselves and friends in the video. Viewers have read-only access. Both editors and viewers can access the video even if it is private (to make videos uploaded by your partner account private by default, please let us know via email).

You can get the current list of editors on a video using getVideoEditors(). Use setVideoEditors() to set both editor and viewer access (up to 8 emails each). Note that setVideoEditors() replaces the existing editors and viewers lists entirely.

// Get current editors
const editors = await pbv.getVideoEditors(vid);

// Set editors and viewers (replaces any previous lists)
await pbv.setVideoEditors(
  vid,
  ['editor1@example.com', 'editor2@example.com'],  // editors
  ['viewer1@example.com']                           // viewers
);

After Video Processing is Done

When our AI is done processing your video, we will email the players in the game (if their email addresses were provided via userEmails). These users will be "editors" on the video and be able to tag themselves and their friends.

If you provided a webhook, then we'll send an HTTP POST request to your server. Your server should acknowledge this callback with a standard 200 (OK) response. If it does not, we will attempt to retry sending this request later (up to some maximum number of attempts).

The HTTP POST body will contain JSON which looks like this (depending on which data is enabled for your API key, only some of these fields may be present):

{
    "from_url": "https://example.com/my-video.mp4",
    "webpage": "https://pb.vision/video/83gyqyc10y8f",
    "cv": CV_DATA,
    "insights": INSIGHTS_DATA,
    "stats": STATS_DATA,
    "vid": STRING,
    "aiEngineVersion": INT,
    "error": {
        "reason": "some explanation here..."
    }
}

Callback Data

  • from_url is the video url you sent us in step 3
  • webpage is a link to our web app where the stats can be explored
  • error is only present if your video could not be processed
  • cv contains low-level frame-by-frame data
  • insights describes the pickleball game in a detailed, shot-by-shot format
  • stats various stats about the game for advanced players
  • only included if insights is included:
    • vid - the unique ID of the video in our system
    • aiEngineVersion - the version number of our AI used to process the video

Fetching Insights by Video ID

If you need to retrieve the insights data outside of the webhook callback (for example, to re-fetch data for a previously processed video), you can use a simple HTTP GET request with the video ID:

curl https://api-2o2klzx4pa-uc.a.run.app/video/VIDEO_ID/insights.json

Webhook callbacks with include.insights receive the raw insights JSON from storage. This endpoint is a separate convenience endpoint; by default, it returns a compact representation of the same session data. Add ?format=augmented for readable field names:

curl 'https://api-2o2klzx4pa-uc.a.run.app/video/VIDEO_ID/insights.json?format=augmented'

For multi-game videos, pass the 1-indexed session number:

curl 'https://api-2o2klzx4pa-uc.a.run.app/video/VIDEO_ID/insights.json?sessionNum=2&format=augmented'

You can call this endpoint as many times as needed.

Player Identification

PB Vision assigns each detected player an index based on visual detection. Players are indexed 0-3 for doubles (0-1 on one team, 2-3 on the other) and 0 and 2 for singles. These indices are consistent within a single video but do not carry over between videos, so "Player 0" in one video is not necessarily the same person as "Player 0" in another.

Player thumbnails are available after processing. Using the vid and aiEngineVersion from the webhook callback, you can fetch thumbnail images for each player:

https://storage.googleapis.com/pbv-pro/{vid}/{aiEngineVersion}/player{playerIndex}-{imageIndex}.jpg
  • playerIndex: 0-3 for doubles, 0 and 2 for singles
  • imageIndex: 0-7 (up to 8 thumbnails per player, captured at different points in the game)

For example, to get thumbnails for all four players in a doubles game:

https://storage.googleapis.com/pbv-pro/83gyqyc10y8f/7/player0-0.jpg
https://storage.googleapis.com/pbv-pro/83gyqyc10y8f/7/player1-0.jpg
https://storage.googleapis.com/pbv-pro/83gyqyc10y8f/7/player2-0.jpg
https://storage.googleapis.com/pbv-pro/83gyqyc10y8f/7/player3-0.jpg

Mapping players to your system: If your integration needs to know which player is which (e.g. linking game stats to player profiles in your app), you have a few options:

  1. Pass player emails at upload time via the userEmails metadata field. If you know which players are in the match, their emails will be associated with the video as editors, and you can match them against your records. Note that providing an email associates the video with that PB Vision account, but it does not automatically identify which of the detected players (avatar_id) belongs to that email. That mapping happens on your side using the thumbnails or webpage link below.

  2. Use thumbnails for manual or automated matching. After processing, fetch the player thumbnails and either surface them in an admin UI for manual confirmation, or compare them against known player photos programmatically. If thumbnails alone aren't enough, show the PB Vision webpage link next to the avatar choices (or embed it in an iframe) so the user can reference the video before selecting themselves.

  3. Store your own metadata alongside the video ID. When you upload a video, record the returned vid alongside whatever context you have (match ID, player roster, season, week, etc.) in your own system. When the webhook fires, use the vid to look up that context and route the results accordingly.

The insights JSON also includes an avatar_id for each player, which corresponds to the playerIndex used in the thumbnail URLs above.

Video Guidelines

Note: We are now able to split videos into individual games if you'd like to upload more than one game per video. Let us know if this applies to your use case.

Requirements:

For best results, we also recommend:

  • File Extension: .mp4
  • Audio Encoding: MPEG-4 AAC
  • Resolution: 1080p
  • Frame Rate: 30 FPS
  • Max Bitrate: 4 Mbps
  • Max File Size: 2GB
